CLS-83AWC *[$129.99-]
8.4V@83.5kg/1159.8oz
8.4V@0.10sec
IP=Ingress Protection Rating
6=Dust Tight / 7=Immersion up to 1 Meter depth of 30 minutes
[ Including 1 piece of 15T Lockable Aluminum Arm ]
DETAILS
Application / Suitable
| 1/4、1/5th Buggy ( Off-Road ), GT ( On-road ), Monster Truck, Rock Crawler & Large Boats. |
Specifications
| Torque At 6.0V |
60.8 kg-cm / 844.5 oz-in |
| Torque At 7.4V |
77.7 kg-cm / 1079.3 oz-in |
| Torque At 8.4V |
83.5 kg-cm / 1159.8 oz-in |
| Speed At 6.0V |
0.14 sec / 60° |
| Speed At 7.4V |
0.11 sec / 60° |
| Speed At 8.4V |
0.10 sec / 60° |
Protection Mechanism
| Soft Start Protection |
Soft start back to the neutral position. |
| Over Voltage Protection |
Over 9.0V drive the protection mode, and 8.4V return to normal mode. |
| Low Voltage Protection |
Lower than 4.0V, drive the protection mode, and 4.5V return to normal mode. |
| Locked Rotor Protection |
Stall in 5 sec, output torque goes down. |
| Temperature Protection |
Overheat 85 degrees C (185 degrees F), drive the protection mode, and down 75 degrees C (167 degrees F) return to normal mode. |
| Lose Control Protection |
When losing the transmitter signal, that servo will immediately be back to the neutral position and locked. |
Power Supply
| Operating Voltage Range |
4.5V ~ 8.5V ( 4 ~ 6 Cell Ni-MH or 2S Li-Poly / 2S Li-Fe) |
Control Specification
| Control System |
Higher-order Algorithm 32-bit MCU (Microcontroller Unit)
Frequency：Up to 400Hz & 1500us or 1520us |
| Frame Rate (Signal repeat rate) |
Under 1ms【Compatible with SR & SXR Dual-Mode】 |
| Dead Band Width |
0.002ms ( Default：2us) |
Mechanical Specifications
| Ball Bearing |
Dual, Stronger Ball Bearings with 1 piece of oil seal.【NMB from Japan】 |
| Gear |
Stainless Steel Output Gear With All Steel Gears |
| Motor |
High-Efficiency Coreless Motor |
| Horn / Gear Spline |
15 Teeth ( Universal Type ) |
| Connected Cable Length |
300 mm (11.81 in) [ Black Cladding Cable Edition ] |
Physical Specifications
| Dimension (mm) |
65.8 x 30 x 56.5 mm / 2.59 x 1.18 x 2.22 in |
| Weight (gram) |
245.0 ± 1 grams / 8.64 oz |
| Product Picture / Dimension Sketch |
-2(1).png) |
