Large Scale [Incl. Water-Proof Series]

CLS-93AWC *[$139.99-]

8.4V@93.3kg/1295.9oz
8.4V@0.13sec
※ Begin from September 2021, SR/SXR Dual-Mode functions have been added.
IP=Ingress Protection Rating
6=Dust Tight / 7=Immersion up to 1 Meter depth of 30 minutes
[ Including 1 piece of 15T Lockable Aluminum Arm ]
DETAILS
Application / Suitable
1/4、1/5th Buggy ( Off-Road ), GT ( On-road ), Monster Truck, Rock Crawler & Large Boats.

Specifications
Torque At 6.0V 72.2 kg-cm / 1002.8 oz-in
Torque At 7.4V 87.5 kg-cm / 1215.4 oz-in
Torque At 8.4V 93.3 kg-cm / 1295.9 oz-in
Speed At 6.0V 0.19 sec / 60°
Speed At 7.4V 0.15 sec / 60°
Speed At 8.4V 0.13 sec / 60°

Protection Mechanism
Soft Start Protection Soft start back to a neutral position.
Over Voltage Protection Over 9.0V drive the protection mode, and 8.4V return to normal mode.
Low Voltage Protection Lower than 4.0V, drive the protection mode, and 4.5V return to normal mode.
Locked Rotor Protection Stall in 5 sec, output torque goes down.
Temperature Protection Overheat 85 degrees C (185 degrees F), drive the protection mode and down 75 degrees C (167 degrees F) return to normal mode.
Lose Control Protection When losing the transmitter signal, that servo will immediately be back to the neutral position and locked.

Power Supply
Operating Voltage Range  4.5V ~ 8.5V ( 4 ~ 6 Cell Ni-MH or 2S Li-Poly / 2S Li-Fe)

Control Specification
Control System Higher-order Algorithm 32-bit MCU (Microcontroller Unit)
Frequency：Up to 400Hz & 1500us or 1520us
Frame Rate (Signal repeat rate) Under 1ms【Compatible with SR & SXR Dual-Mode】
Dead Band Width 0.002ms ( Default：2us)

Mechanical Specifications
Ball Bearing Dual, Stronger Ball Bearings with 1 piece of oil seal.【NMB from Japan】
Gear Stainless Steel Output Gear With All Steel Gears
Motor High-Efficiency Coreless Motor
Horn / Gear Spline 15 Teeth ( Universal Type )
Connected Cable Length 300 mm (11.81 in) [ Black Cladding Cable Edition ]

Physical Specifications
Dimension (mm) 65.8 x 30 x 56.5 mm / 2.59 x 1.18 x 2.22 in
Weight (gram) 245.0 ± 1 grams / 8.64 oz
Product Picture / Dimension Sketch
